Expandable
Expandable
Expandable Card primitive to easily condense and expand details
In 15 mins
Design Sync
1:30PM → 2:30PM
WeeklyNext: Mon, 10:00 AM
New Arrival
$129.99
Sony Headphones
(128)
72°F
72°F
Feels like 75°F
Sunny
Last updated: 5 minutes ago
References
Inspiration
Installation
Copy and paste the following code into your project.
"use client"
import React, {
ReactNode,
createContext,
useContext,
useEffect,
useState,
} from "react"
import {
AnimatePresence,
HTMLMotionProps,
TargetAndTransition,
motion,
useMotionValue,
useSpring,
} from "motion/react"
import useMeasure from "react-use-measure"
import { cn } from "@/lib/utils"
const springConfig = { stiffness: 200, damping: 20, bounce: 0.2 }
interface ExpandableContextType {
isExpanded: boolean // Indicates whether the component is expanded
toggleExpand: () => void // Function to toggle the expanded state
expandDirection: "vertical" | "horizontal" | "both" // Direction of expansion
expandBehavior: "replace" | "push" // How the expansion affects surrounding content
transitionDuration: number // Duration of the expansion/collapse animation
easeType: string // Easing function for the animation
initialDelay: number // Delay before the animation starts
onExpandEnd?: () => void // Callback function when expansion ends
onCollapseEnd?: () => void // Callback function when collapse ends
}
// Create a context with default values
const ExpandableContext = createContext<ExpandableContextType>({
isExpanded: false,
toggleExpand: () => {},
expandDirection: "vertical", // 'vertical' | 'horizontal' | 'both' // Direction of expansion
expandBehavior: "replace", // How the expansion affects surrounding content
transitionDuration: 0.3, // Duration of the expansion/collapse animation
easeType: "easeInOut", // Easing function for the animation
initialDelay: 0,
})
// Custom hook to use the ExpandableContext
const useExpandable = () => useContext(ExpandableContext)
type ExpandablePropsBase = Omit<HTMLMotionProps<"div">, "children">
interface ExpandableProps extends ExpandablePropsBase {
children: ReactNode | ((props: { isExpanded: boolean }) => ReactNode)
expanded?: boolean
onToggle?: () => void
transitionDuration?: number
easeType?: string
expandDirection?: "vertical" | "horizontal" | "both"
expandBehavior?: "replace" | "push"
initialDelay?: number
onExpandStart?: () => void
onExpandEnd?: () => void
onCollapseStart?: () => void
onCollapseEnd?: () => void
}
// ROOT Expand component
const Expandable = React.forwardRef<HTMLDivElement, ExpandableProps>(
(
{
children,
expanded,
onToggle,
transitionDuration = 0.3,
easeType = "easeInOut",
expandDirection = "vertical",
expandBehavior = "replace",
initialDelay = 0,
onExpandStart,
onExpandEnd,
onCollapseStart,
onCollapseEnd,
...props
},
ref
) => {
// Internal state for expansion when the component is uncontrolled
const [isExpandedInternal, setIsExpandedInternal] = useState(false)
// Use the provided expanded prop if available, otherwise use internal state
const isExpanded = expanded !== undefined ? expanded : isExpandedInternal
// Use the provided onToggle function if available, otherwise use internal toggle function
const toggleExpand =
onToggle || (() => setIsExpandedInternal((prev) => !prev))
// Effect to call onExpandStart or onCollapseStart when isExpanded changes
useEffect(() => {
if (isExpanded) {
onExpandStart?.()
} else {
onCollapseStart?.()
}
}, [isExpanded, onExpandStart, onCollapseStart])
// Create the context value to be provided to child components
const contextValue: ExpandableContextType = {
isExpanded,
toggleExpand,
expandDirection,
expandBehavior,
transitionDuration,
easeType,
initialDelay,
onExpandEnd,
onCollapseEnd,
}
return (
<ExpandableContext.Provider value={contextValue}>
<motion.div
ref={ref}
initial={false}
animate={{
transition: {
duration: transitionDuration,
ease: easeType,
delay: initialDelay,
},
}}
{...props}
>
{/* Render children as a function if provided, otherwise render as is */}
{typeof children === "function" ? children({ isExpanded }) : children}
</motion.div>
</ExpandableContext.Provider>
)
}
)
// Simplify animation types
type AnimationPreset = {
initial: { [key: string]: any }
animate: { [key: string]: any }
exit: { [key: string]: any }
}
// Update ANIMATION_PRESETS type
const ANIMATION_PRESETS: Record<string, AnimationPreset> = {
fade: {
initial: { opacity: 0 },
animate: { opacity: 1 },
exit: { opacity: 0 },
},
"slide-up": {
initial: { opacity: 0, y: 20 },
animate: { opacity: 1, y: 0 },
exit: { opacity: 0, y: 20 },
},
"slide-down": {
initial: { opacity: 0, y: -20 },
animate: { opacity: 1, y: 0 },
exit: { opacity: 0, y: -20 },
},
"slide-left": {
initial: { opacity: 0, x: 20 },
animate: { opacity: 1, x: 0 },
exit: { opacity: 0, x: 20 },
},
"slide-right": {
initial: { opacity: 0, x: -20 },
animate: { opacity: 1, x: 0 },
exit: { opacity: 0, x: -20 },
},
scale: {
initial: { opacity: 0, scale: 0.8 },
animate: { opacity: 1, scale: 1 },
exit: { opacity: 0, scale: 0.8 },
},
rotate: {
initial: { opacity: 0, rotate: -10 },
animate: { opacity: 1, rotate: 0 },
exit: { opacity: 0, rotate: -10 },
},
"blur-sm": {
initial: { opacity: 0, filter: "blur(4px)" },
animate: { opacity: 1, filter: "blur(0px)" },
exit: { opacity: 0, filter: "blur(4px)" },
},
"blur-md": {
initial: { opacity: 0, filter: "blur(8px)" },
animate: { opacity: 1, filter: "blur(0px)" },
exit: { opacity: 0, filter: "blur(8px)" },
},
"blur-lg": {
initial: { opacity: 0, filter: "blur(16px)" },
animate: { opacity: 1, filter: "blur(0px)" },
exit: { opacity: 0, filter: "blur(16px)" },
},
}
// Update type definitions
type AnimationConfig = {
initial: { [key: string]: number | string }
animate: { [key: string]: number | string }
exit: { [key: string]: number | string }
}
// Props for defining custom animations
interface AnimationProps {
initial?: TargetAndTransition
animate?: TargetAndTransition
exit?: TargetAndTransition
transition?: any
}
// Inside ExpandableContent component
const getAnimationProps = (
preset: keyof typeof ANIMATION_PRESETS | undefined,
animateIn?: AnimationProps,
animateOut?: AnimationProps
) => {
const defaultAnimation = {
initial: {},
animate: {},
exit: {},
}
const presetAnimation = preset ? ANIMATION_PRESETS[preset] : defaultAnimation
return {
initial: presetAnimation.initial,
animate: presetAnimation.animate,
exit: animateOut?.exit || presetAnimation.exit,
}
}
// Wrap this around items in the card that you want to be hidden then animated in on expansion
const ExpandableContent = React.forwardRef<
HTMLDivElement,
Omit<HTMLMotionProps<"div">, "ref"> & {
preset?: keyof typeof ANIMATION_PRESETS
animateIn?: AnimationProps
animateOut?: AnimationProps
stagger?: boolean
staggerChildren?: number
keepMounted?: boolean
}
>(
(
{
children,
preset,
animateIn,
animateOut,
stagger = false,
staggerChildren = 0.1,
keepMounted = false,
...props
},
ref
) => {
const { isExpanded, transitionDuration, easeType } = useExpandable()
// useMeasure is used to measure the height of the content
const [measureRef, { height: measuredHeight }] = useMeasure()
// useMotionValue creates a value that can be animated smoothly
const animatedHeight = useMotionValue(0)
// useSpring applies a spring animation to the height value
const smoothHeight = useSpring(animatedHeight, springConfig)
useEffect(() => {
// Animate the height based on whether the content is expanded or collapsed
if (isExpanded) {
animatedHeight.set(measuredHeight)
} else {
animatedHeight.set(0)
}
}, [isExpanded, measuredHeight, animatedHeight])
const animationProps = getAnimationProps(preset, animateIn, animateOut)
return (
// This motion.div animates the height of the content
<motion.div
ref={ref}
style={{
height: smoothHeight,
overflow: "hidden",
}}
transition={{ duration: transitionDuration, ease: easeType }}
{...props}
>
{/* AnimatePresence handles the entering and exiting of components */}
<AnimatePresence initial={false}>
{(isExpanded || keepMounted) && (
// This motion.div handles the animation of the content itself
<motion.div
ref={measureRef}
initial={animationProps.initial}
animate={animationProps.animate}
exit={animationProps.exit}
transition={{ duration: transitionDuration, ease: easeType }}
>
{stagger ? (
// If stagger is true, we apply a staggered animation to the children
<motion.div
variants={{
hidden: {},
visible: {
transition: {
staggerChildren: staggerChildren,
},
},
}}
initial="hidden"
animate="visible"
>
{React.Children.map(
children as React.ReactNode,
(child, index) => (
<motion.div
key={index}
variants={{
hidden: { opacity: 0, y: 20 },
visible: { opacity: 1, y: 0 },
}}
>
{child}
</motion.div>
)
)}
</motion.div>
) : (
children
)}
</motion.div>
)}
</AnimatePresence>
</motion.div>
)
}
)
interface ExpandableCardProps {
children: ReactNode
className?: string
collapsedSize?: { width?: number; height?: number } // Size when collapsed
expandedSize?: { width?: number; height?: number } // Size when expanded
hoverToExpand?: boolean // Whether to expand on hover
expandDelay?: number // Delay before expanding
collapseDelay?: number // Delay before collapsing
}
const ExpandableCard = React.forwardRef<HTMLDivElement, ExpandableCardProps>(
(
{
children,
className = "",
collapsedSize = { width: 320, height: 211 },
expandedSize = { width: 480, height: undefined },
hoverToExpand = false,
expandDelay = 0,
collapseDelay = 0,
...props
},
ref
) => {
// Get the expansion state and toggle function from the ExpandableContext
const { isExpanded, toggleExpand, expandDirection } = useExpandable()
// Use useMeasure hook to get the dimensions of the content
const [measureRef, { width, height }] = useMeasure()
// Create motion values for width and height
const animatedWidth = useMotionValue(collapsedSize.width || 0)
const animatedHeight = useMotionValue(collapsedSize.height || 0)
// Apply spring animation to the motion values
const smoothWidth = useSpring(animatedWidth, springConfig)
const smoothHeight = useSpring(animatedHeight, springConfig)
// Effect to update the animated dimensions when expansion state changes
useEffect(() => {
if (isExpanded) {
animatedWidth.set(expandedSize.width || width)
animatedHeight.set(expandedSize.height || height)
} else {
animatedWidth.set(collapsedSize.width || width)
animatedHeight.set(collapsedSize.height || height)
}
}, [
isExpanded,
collapsedSize,
expandedSize,
width,
height,
animatedWidth,
animatedHeight,
])
// Handler for hover start event
const handleHover = () => {
if (hoverToExpand && !isExpanded) {
setTimeout(toggleExpand, expandDelay)
}
}
// Handler for hover end event
const handleHoverEnd = () => {
if (hoverToExpand && isExpanded) {
setTimeout(toggleExpand, collapseDelay)
}
}
return (
<motion.div
ref={ref}
className={cn("cursor-pointer", className)}
style={{
// Set width and height based on expansion direction
width:
expandDirection === "vertical" ? collapsedSize.width : smoothWidth,
height:
expandDirection === "horizontal"
? collapsedSize.height
: smoothHeight,
}}
transition={springConfig}
onHoverStart={handleHover}
onHoverEnd={handleHoverEnd}
{...props}
>
<div
className={cn(
"grid grid-cols-1 rounded-lg sm:rounded-xl md:rounded-[2rem]",
"shadow-[inset_0_0_1px_1px_#ffffff4d] sm:shadow-[inset_0_0_2px_1px_#ffffff4d]",
"ring-1 ring-black/5",
"max-w-[calc(100%-1rem)] sm:max-w-[calc(100%-2rem)] md:max-w-[calc(100%-4rem)]",
"mx-auto w-full",
"transition-all duration-300 ease-in-out"
)}
>
{/* Nested divs purely for styling and layout (the shadow ring around the card) */}
<div className="grid grid-cols-1 rounded-lg sm:rounded-xl md:rounded-[2rem] p-1 sm:p-1.5 md:p-2 shadow-md shadow-black/5">
<div className="rounded-md sm:rounded-lg md:rounded-3xl bg-white p-2 sm:p-3 md:p-4 shadow-xl ring-1 ring-black/5">
<div className="w-full h-full overflow-hidden">
{/* Ref for measuring content dimensions (so we can let framer know to animate into the dimensions) */}
<div ref={measureRef} className="flex flex-col h-full">
{children}
</div>
</div>
</div>
</div>
</div>
</motion.div>
)
}
)
ExpandableCard.displayName = "ExpandableCard"
// I'm telling you we just have to expand 🤌💵
const ExpandableTrigger = React.forwardRef<
HTMLDivElement,
React.HTMLAttributes<HTMLDivElement>
>(({ children, ...props }, ref) => {
const { toggleExpand } = useExpandable()
return (
<div ref={ref} onClick={toggleExpand} className="cursor-pointer" {...props}>
{children}
</div>
)
})
ExpandableTrigger.displayName = "ExpandableTrigger"
const ExpandableCardHeader = React.forwardRef<
HTMLDivElement,
React.HTMLAttributes<HTMLDivElement>
>(({ className, children, ...props }, ref) => (
<div
ref={ref}
className={cn("flex flex-col space-y-1.5 p-6", className)}
{...props}
>
<motion.div layout className="flex justify-between items-start">
{children}
</motion.div>
</div>
))
ExpandableCardHeader.displayName = "ExpandableCardHeader"
const ExpandableCardContent = React.forwardRef<
HTMLDivElement,
React.HTMLAttributes<HTMLDivElement>
>(({ className, children, ...props }, ref) => (
<div
ref={ref}
className={cn("p-6 pt-0 px-4 overflow-hidden flex-grow", className)}
{...props}
>
<motion.div layout>{children}</motion.div>
</div>
))
ExpandableCardContent.displayName = "ExpandableCardContent"
const ExpandableCardFooter = React.forwardRef<
HTMLDivElement,
React.HTMLAttributes<HTMLDivElement>
>(({ className, ...props }, ref) => (
<div
ref={ref}
className={cn("flex items-center p-4 pt-0", className)}
{...props}
/>
))
ExpandableCardFooter.displayName = "ExpandableCardFooter"
export {
Expandable,
useExpandable,
ExpandableCard,
ExpandableContent,
ExpandableContext,
ExpandableTrigger,
ExpandableCardHeader,
ExpandableCardContent,
ExpandableCardFooter,
}
